14" – 50" Tall - Wet listed Wall Mount

Material: Steel housing and chassis
Lens Material: UV-stabilized high-impact-resistant DR acrylic; top and bottom white acrylic lens standard; optional lens cover (NCL)
Mounting: Wall mount — keyhole slots left and right
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: MANW-914: 14" H × 9" W × 5" D
Dimensions: MANW-916: 16" H × 9" W × 5" D
Dimensions: MANW-920: 20" H × 9" W × 5" D
Dimensions: MANW-926: 26" H × 9" W × 5" D
Dimensions: MANW-938: 38" H × 9" W × 5" D
Dimensions: MANW-950: 50" H × 9" W × 5" D

Replaceable LED Module: Yes — field replaceable

3-Step MacAdam Binning: Standard

Lumens: Source lumens — see configuration table

Lumen Maintenance: > 60,000 hours

Integral Driver: Standard

Dimming: 0–10V; TRIAC/ELV on qualifying configurations — consult factory.

Voltage: 120–277V universal standard

CRI: > 90 Standard

CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K

Energy Star: Yes — on select configurations

Title 24 / JA8: Yes — on select configurations

UL / CUL Listing: UL and CUL Listed — WET location

Warranty: 5-year warranty on LED components with optional 10-year warranty available

The MANW-900-LED scales the MANW half-round outdoor sconce to a 9" profile, appropriate for larger building façades, high-ceilinged entries, and exterior applications where the 600 Series would appear undersized. Its six cage options and BABA compliance make it a strong architectural and procurement specification.



•   Large building entries and hotel exterior façades

•   Multifamily residential building exteriors and breezeways requiring mid-scale fixtures

•   Healthcare campus and institutional building perimeters

•   Municipal and civic building exteriors

•   Resort and hospitality property exteriors



•   Six heights: 14", 16", 20", 26", 38", 50" — all 9" wide

•   Six cage style options (A–F plus custom X)

•   Optional lens cover (NCL) to eliminate up/down light

•   0–10V dimming; TRIAC/ELV on qualifying configurations

•   Optional photocell (120V or 277V)

•   Optional battery backup (BB10 — 10 W, 90 min; 0–10V only)

•   Optional J-box with knockouts on all sides (option 39)

•   Energy Star listed — select configurations

•   Title 24 / JA8 — select configurations

•   BABA compliant — made in America

•   5-year LED component warranty (optional 10-year available)

•   UL and CUL Listed — WET location
