MNBW
14" or 16" Tall Wet Listed Wall Lighting
The MNBW LED Series delivers a bold, modern architectural presence with its deep 6.25" profile and square housing available in 14" and 16" sizes. The fixture features a durable white textured or smooth polycarbonate lens that provides uniform, diffused illumination while maintaining excellent impact resistance. The steel housing and chassis create a clean, structured silhouette suitable for both contemporary and traditional building façades. The 14" model uses a center lockup mounting system for secure installation, while the 16" model incorporates bi‑directional keyhole slots for added flexibility. With CRI > 90, universal 120/277V operation, and UL/CUL Wet Location certification, the MNBW Series is engineered for long‑term performance in commercial, hospitality, and multi‑family environments. Proudly made in America, with BABA‑compliant options always available.
Resources
- Steel housing and steel chassis
- Lens options:
- WTP White Textured Polycarbonate
- WSP White Smooth Polycarbonate
- Optional BSA Blue Smooth Acrylic
- 14" model: center lockup mounting
- 16" model: bi‑directional keyhole slots
- Height: 14" or 16"
- Width: 14.25" (14") or 13.5" (16")
- Depth: 6.25"
LED light source
Dimming to 10% included (0–10V or TRIAC/ELV depending on LED engine)
CRI > 90
Replaceable LED module
Universal 120/277V standard
UL and CUL Wet Location listed
5‑year warranty on LED components
Dimming to 10% included (0–10V or TRIAC/ELV depending on LED engine)
CRI > 90
Replaceable LED module
Universal 120/277V standard
UL and CUL Wet Location listed
5‑year warranty on LED components
Features & Benefits
Wet Location rated for indoor or outdoor use
Durable polycarbonate lens options for uniform, diffused illumination
High‑efficiency LED system with CRI > 90
Multiple wattage and lumen packages for application flexibility
Optional line‑voltage TRIAC/ELV dimming (DIMLD)
Proudly made in America
BABA‑compliant options always available
Wet Location rated for indoor or outdoor use
Durable polycarbonate lens options for uniform, diffused illumination
High‑efficiency LED system with CRI > 90
Multiple wattage and lumen packages for application flexibility
Optional line‑voltage TRIAC/ELV dimming (DIMLD)
Proudly made in America
BABA‑compliant options always available
Ideally Suited For
A strong choice for multi‑family exteriors and breezeways
Well‑matched to hospitality entries and architectural accent lighting
A dependable option for schools, municipal buildings, and public facilities
Great for commercial exteriors requiring Wet Location durability
Useful anywhere needing a robust, diffused‑lens wall fixture with modern styling
A strong choice for multi‑family exteriors and breezeways
Well‑matched to hospitality entries and architectural accent lighting
A dependable option for schools, municipal buildings, and public facilities
Great for commercial exteriors requiring Wet Location durability
Useful anywhere needing a robust, diffused‑lens wall fixture with modern styling
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 800
- 863
- 1230
- 1600
- 2460
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV (Trailing Edge)
- Phase Dimming
- Triac (Leading Edge)
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 6
- 10
- 12
- 24
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
