MITWMITW
10" – 50" Tall - Wet listed Wall Mount
The MITW‑LED Series combines rugged construction with clean architectural styling to create a versatile wall‑mounted LED solution for building exteriors, walkways, parking structures, and perimeter lighting. Built with a steel housing and chassis and paired with a UV‑stabilized, high‑impact DR acrylic diffuser, the MITW‑LED provides uniform, dependable illumination while withstanding harsh outdoor conditions.
Engineered for long‑term performance, the fixture includes a replaceable LED module, universal 120/277V operation, and dimming to 10%. It is UL and CUL listed for wet locations, ensuring suitability for exposed environments. Optional features include a photocell, all‑aluminum construction, and battery backup for emergency egress requirements. With multiple sizes, lumen packages, finishes, and color temperatures, the MITW‑LED adapts easily to a wide range of project needs. Proudly made in America, the series also offers Build America, Buy America Act (BABA) compliant configurations for federally funded projects.
Resources
- Steel housing and chassis
- UV‑stabilized, high‑impact resistant DR acrylic diffuser
- Integral mounting plate; hardware included
- Optional all‑aluminum construction (Option 42)
- Optional photocell (Option 21) — increases fixture depth by 1 1/2"
- Dimensions:
- MITW‑916: 16" height × 9" width × 8" M.C.
- MITW‑920: 20" height × 9" width × 10" M.C.
- MITW‑926: 26" height × 9" width × 13" M.C.
- LED light source
- Dimming to 10% included (0–10V or TRIAC/ELV depending on LED engine)
- CRI > 90
- Replaceable LED module
- Universal 120/277V standard
- Optional photocell (21) —
- Specify voltage (01 = 120V, 02 = 277V); increases depth 1.5"
- Optional battery backup (BB10) — 10W, 1170 lm, 90 minutes (0–10V only)
- UL and CUL Wet Location listed
- 5‑year warranty on LED components
Features & Benefits
- Proudly made in America
- BABA‑compliant options always available
- UV‑stabilized diffuser resists yellowing and impact damage
- Multiple sizes for scalable illumination across building elevations
- Optional photocell for dusk‑to‑dawn operation
- Optional all‑aluminum construction for corrosion‑resistant environments
- High‑efficiency LED system reduces maintenance and energy costs
- Ideal for multi‑family housing, commercial buildings, parking structures, and perimeter lighting
- Durable construction suitable for harsh outdoor environments
Ideally Suited For
- A strong choice for multi‑family exteriors and breezeways
- Well‑matched to hospitality entries and architectural accent lighting
- A dependable option for schools, municipal buildings, and public facilities
- Great for commercial exteriors requiring Wet Location durability
- Useful anywhere needing a tall, narrow, impact‑resistant wall fixture
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 2420
- 4000
- 4840
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 18
- 29
- 36
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
