TUSBTUSB
Bollard & Pathway Lighting
The TUSB-LED is a steel-housed path and landscape light designed to mount atop a post for low-level walkway and garden illumination. A clear tempered-glass lens protects the LED source, and the fixture is available with a standard select cedar direct-burial post, sized for the installer to field-cut to the desired height, or an optional steel post with a square flange base and anchor bolts for a more refined commercial look.
The TUSB-LED is offered in a wide range of designer finishes and ships dimmable to 10% standard, with an optional photocell for dusk-to-dawn operation. It shares its design language with the companion TUSW wall sconce, allowing coordinated path and wall lighting on a single project.
Dark Sky compliant and wet-location UL/CUL listed, the TUSB-LED is backed by Lightway's standard LED component warranty.
Resources
Material: Steel housing and chassis
Lens Material: Clear tempered glass
Mounting: Post-mounted: standard cedar direct-burial post (4x6x60", field-cut to height) or optional 4" square steel post (36" tall) with flange base, cover, and anchor bolts
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: TUSB-8: 7" H x 8¼" W x 8⅜" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Available as an ordering option (ES)
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The TUSB-LED brings coordinated, low-level path lighting to gardens and landscapes, with a choice of natural cedar or steel post and a companion wall sconce for unified property-wide design.
Ideally Suited For
• Garden and landscape pathways
• Residential walkways and courtyards
• Low-level post lighting for parks and HOA common areas
• Coordinated installations with the companion TUSW wall sconce
Key Features & Options
• Choice of standard cedar direct-burial post or optional steel post
• Dimmable to 10% standard
• Optional photocell (120V or 277V)
• Energy Star listed components available as an option
• Companion wall fixture available (TUSW)
• Dark Sky compliant
• Wet-location UL/CUL listing
• Proudly made in America; BABA-compliant options always available
• 5-year warranty on LED components, with optional 10-year warranty available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- DarkSky Approved
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 800
- 1600
Dimming Protocol
- 0-10 V
CRI
- 91
Shape
- Triangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
- Wood
Watts
- 6
- 12
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Distribution
- Type V
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Circuit
- Single
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
