SNLH
SNLH Application Photo.jpgSNLH
24- or 48" long Damp Listed Pendent
The SNLH-LED linear pendant features an aluminum chassis with an extruded white smooth acrylic diffuser, delivering ambient light outward while a bottom-mounted MR16 downlight provides task lighting on a separate circuit. The canopy mounts to a standard J-Box, and the standard suspension is a single 15-degree swivel stem (1S15). Custom mounting heights can be specified.
Available in two sizes — 26" and 48" — the SNLH-LED includes dimming to 10% standard on the ambient light source, with the MR16 downlight available as non-dimmable on a separate circuit, or tied to the non-dimming side of the ambient light.
UL and CUL listed for DAMP locations. Backed by a 5-year warranty on LED components.
Resources
Material: Aluminum chassis
Lens Material: Extruded white smooth acrylic
Mounting: Canopy mounts to standard J-Box; standard single 15° swivel stem (1S15); custom heights available
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: SNLH-26-LED: H 26" × W 6" dia × D OAH 36" std
SNLH-48-LED: H 48" × W 6" dia × D OAH 60" std
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The SNLH-LED from Lightway brings American craftsmanship and engineering excellence to exterior and architectural lighting. Combining enduring design with state-of-the-art LED technology, it is an ideal choice for projects requiring long-term performance, design versatility, and compliance confidence. Field-replaceable LED modules ensure easy maintenance, and a comprehensive range of finishes and lens options make specification straightforward for any project.
Ideally Suited For:
• Commercial lobbies and reception areas
• Hospitality dining and bar areas
• Retail accent and task lighting
• Office and conference room ceilings
• Combined ambient and task lighting applications
Key Features & Options:
• Integrated MR16 downlight on separate circuit
• Outward-facing LEDs for ambient light
• Two sizes: 26" and 48"
• Single 15° swivel stem suspension (1S15)
• Custom mounting heights available
• 5-year LED warranty
• BABA compliant — proudly made in America
• Field-replaceable LED module
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Made in America
- RoHS
Lumens
- 6
- 16
- 4840
- 6015
Dimming Protocol
- 0-10 V
CRI
- 91
Shape
- Tubular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 36
- 50
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
