Petite 5" Tall 15" Wide Wet Listed Wall Lighting

Material: Steel housing and chassis; optional all-aluminum construction
Lens Material: Clear smooth acrylic standard; optional white frosted acrylic lens
Mounting: Universal mounting pattern; hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: TUXW-15: 5" H x 15" W x 4" D

Replaceable LED Module: Yes — field replaceable

3-Step MacAdam Binning: Standard

Lumens: Source lumens — see configuration table

Lumen Maintenance: > 60,000 hours

Integral Driver: Standard

Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.

Voltage: 120–277V universal standard

CRI: > 90 Standard

CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K

UL / CUL Listing: UL and CUL Listed — WET location

Warranty: 5-year warranty on LED components with optional 10-year warranty available

The TUXW-LED offers a slim, ADA-compliant wedge profile for exterior wall lighting where a clean, low-profile silhouette is a priority.

Ideally Suited For
•       Multifamily exterior corridors
•       Hospitality and retail wall lighting
•       Parking structures and stairwells
•       Commercial building exteriors

Key Features & Options
•       Slim 4" depth wedge profile
•       ADA compliant
•       Dimmable to 10% standard
•       Optional all-aluminum construction
•       BUG Rating: B1-U0-G0
•       Build America, Buy America Act compliant
•       Wet-location UL/CUL listing
•       Proudly made in America; BABA-compliant options always available
•       5-year warranty on LED components, with optional 10-year warranty available
