JPCWJPCW
13" Tall Wet Listed Wall Lighting
The JPCW-LED is a mission/craftsman-inspired outdoor wall lantern featuring steel top, bottom, and rings construction. The standard diffuser is .080" thick white textured polycarbonate. Optional premium diffusers include alabaster acrylic lenses (.080" thick) and glass lenses (.125" thick) — available in amber honey alabaster, beige alabaster, opal alabaster, amber honey glass, and clear seedy glass — offering a rich, warm aesthetic suited to traditional and craftsman architectural styles.
An integral mounting plate accommodates a standard J-Box with downward mounting orientation. The fixture supports 0–10V and TRIAC/ELV dimming. An optional photocell (120V or 277V) attaches to the wall mounting bracket for dusk-to-dawn control. Optional battery backup (BB10 — increases depth 1½") is available for 0–10V configurations, and optional 347V input is available for Canadian applications. Optional 90 CRI can be specified through the factory.
The JPCW-LED is Energy Star listed on qualifying configurations, UL and CUL listed for WET locations, and backed by a 5-year warranty on LED components with an optional 10-year term.
Resources
Material: Steel top, bottom, and rings
Lens Material: .080" thick white textured polycarbonate standard; optional alabaster acrylic (.080") — AHA, BAA, OAA; optional glass (.125") — AHG, CSG
Mounting: Integral mounting plate for standard J-Box; mounting orientation downward
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: 12½" H × 6½" W × 8½" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 80 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Available on qualifying configurations (F1O)
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The JPCW-LED delivers craftsman charm and WET-rated durability with a rich selection of glass and alabaster lens options — ideal for traditional and mission-style architectural projects requiring Energy Star credentials.
Ideally Suited For:
• Craftsman and bungalow-style residential entries
• Historic district and heritage commercial buildings
• Hotel and resort exterior corridor lighting
• Municipal and civic building façades
• Retail and mixed-use traditional streetscapes
Key Features & Options:
• Energy Star listed on qualifying configurations
• WET location rated
• Optional alabaster acrylic lenses: amber honey, beige, opal
• Optional glass lenses: amber honey glass, clear seedy glass
• Optional photocell (120V or 277V) for dusk-to-dawn control
• Optional battery backup (BB10 — 10W, 90-minute runtime)
• Optional 347V input voltage
• 0–10V and TRIAC/ELV dimming options
• Field-replaceable LED module
• BABA compliant — proudly made in America
• 5-year warranty; optional 10-year term
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 863
- 1180
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 10
- 12
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
