CMDBCMDB
Wet Listed Pier mounted lighting
The CMDB-LED is a robust pier and post-top mount fixture engineered from corrosion-resistant coated steel housing and chassis for long-term outdoor durability. The standard diffuser is white textured polycarbonate, with optional .080" thick acrylic alabaster lenses — available in amber honey, beige, and opal — for a refined decorative aesthetic. Available in 12" and 16" sizes with a hole for center conduit and custom sizes available.
CRI >90 standard with 0–10V dimming included on qualifying configurations; TRIAC/ELV also available. Optional Energy Star components, photocell (120V or 277V), aluminum construction, and battery backup (0–10V only) expand the specification range. Optional white smooth polycarbonate diffuser is also available.
UL and CUL listed for WET locations and Energy Star listed on qualifying configurations. All LED components carry a 5-year warranty — see the configuration table for full details.
Resources
Material: Corrosion resistant coated steel housing and chassis
Lens Material: White textured polycarbonate standard; optional .080" acrylic alabaster lenses (Amber Honey, Beige, Opal); optional white smooth polycarbonate
Mounting: Mounts to top of pier, corner stone, or pilaster — hole for center conduit
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
CMDB-12: 10" H × 12" W × 12" L
CMDB-16: 11" H × 16" W × 16" L
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed on qualifying configurations
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The CMDB-LED pier and post-top fixture brings CRI >90 LED performance to outdoor entry and landscape environments, with a corrosion-resistant steel body and optional alabaster lenses that elevate curb appeal. Its WET rating, Energy Star listings, and Made-in-America construction make it a proven specification for commercial and institutional outdoor applications.
Ideally Suited For
• Commercial campus and courtyard pier lighting
• Hotel and resort entrance and landscape lighting
• Residential community gatehouse and entry monuments
• Municipal and civic plaza pillar lighting
• Healthcare campus exterior wayfinding
Key Features & Options
• CRI >90 standard — premium color rendering
• UL and CUL listed WET location
• Energy Star listed on qualifying configurations
• Optional alabaster acrylic lenses (Amber Honey, Beige, Opal)
• Optional white smooth polycarbonate diffuser
• Optional photocell (120V or 277V)
• Optional aluminum construction
• Optional battery backup (0–10V only)
• Custom sizes available
• Proudly made in America — BABA compliant options always available
• 5-year LED warranty; optional 10-year warranty available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 1400
- 2115
- 3200
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
CRI
- 91
Shape
- Square
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 9
- 13
- 24
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Installation Type
- New Construction
- Retrofit & Remodel
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
