MEOW Series
MEOWweb.gifMEOW Series
13" – 50" Tall - Wet listed Wall Mount
The MEOW-LED is a refined, thin-profile outdoor LED wall sconce built on a steel housing and chassis, featuring a UV-stabilized, high-impact-resistant DR acrylic diffuser on all five sides for 360° ambient illumination. The slim 4" wide body is available in five heights from 13" to 50", offering a scale-flexible solution that mounts cleanly on any standard junction box via an integral mounting plate.
Standard 0–10V dimming to 10% is included. An optional photocell (adds ½" depth) enables automated dusk-to-dawn operation, and battery backup is available on fixtures 526 and larger for 90-minute emergency runtime. Optional all-aluminum construction provides enhanced corrosion resistance.
The MEOW-LED is ADA compliant, UL and CUL WET location listed, and Build America Buy America Act compliant with a 5-year warranty on LED components.
Resources
Material: Steel housing and chassis
Lens Material: UV-stabilized, high impact resistant DR acrylic (all five sides)
Mounting: Integral mounting plate; mounts on standard J-Box
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: MEOW-513: H 13" × W 4" × D 5½"
MEOW-518: H 18" × W 4" × D 5½"
MEOW-526: H 26" × W 4" × D 5½"
MEOW-538: H 38" × W 4" × D 5½"
MEOW-550: H 50" × W 4" × D 5½"
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0-10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available.
The MEOW-LED's ultra-slim profile and five-sided illumination deliver a floating glow effect, making it a sophisticated choice for ADA-compliant architectural lighting applications.
Ideally Suited For:
• ADA-accessible building entries and pathways
• High-end multifamily residential corridors
• Boutique hotel and resort exterior lighting
• Mixed-use retail and lifestyle center entries
• Healthcare and institutional facility exteriors
Key Features & Options:
• Thin 4" wide profile with five-sided illumination
• ADA compliant at 4" depth
• Five heights: 13" through 50"
• 0–10V dimming standard (to 10%)
• Optional battery backup (526 and larger) — 90 min.
• Optional photocell (120V or 277V)
• Optional all-aluminum construction
• UL/CUL WET location listed
• BABA compliant — made in America
• 5-year LED component warranty
Ideally Suited For:
• ADA-accessible building entries and pathways
• High-end multifamily residential corridors
• Boutique hotel and resort exterior lighting
• Mixed-use retail and lifestyle center entries
• Healthcare and institutional facility exteriors
Key Features & Options:
• Thin 4" wide profile with five-sided illumination
• ADA compliant at 4" depth
• Five heights: 13" through 50"
• 0–10V dimming standard (to 10%)
• Optional battery backup (526 and larger) — 90 min.
• Optional photocell (120V or 277V)
• Optional all-aluminum construction
• UL/CUL WET location listed
• BABA compliant — made in America
• 5-year LED component warranty
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 1210
- 1600
- 2420
- 3630
- 4840
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 9
- 12
- 18
- 27
- 36
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
- Photocell
