YRBVYRBV
18" 24" Damp Listed Linear & Vanity Lighting
The YRBV-LED is a linear wall light built around a steel chassis and front shield, with a white smooth acrylic diffuser on the top and bottom; an optional perforated steel diffuser or a solid top that eliminates up light can be specified to change the fixture's light character.
The fixture mounts to a standard J-box with slotted anchor holes and dims to 10% standard. It is offered in two lengths to fit a range of wall spans.
The YRBV-LED is ADA compliant and damp-location UL/CUL listed, and is backed by Lightway's standard LED component warranty; consult the factory for elevated CRI options.
Resources
Material: Steel chassis and front shield
Lens Material: White smooth acrylic top and bottom diffuser; optional perforated steel top and/or bottom diffuser, or optional solid top to eliminate up light
Mounting: Mounts to a standard J-box with slotted anchor holes
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: YRBV-18: 6" H x 18" L x 4" D
YRBV-24: 6" H x 24" L x 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The YRBV-LED's clean linear profile and configurable up/down light output suit corridors and lobbies that need an ADA-compliant wall light with flexible light distribution.
Ideally Suited For
• Multifamily and hospitality corridors
• Lobby and common-area accent walls
• Office and commercial hallways
• Retrofit projects needing multiple length options
Key Features & Options
• ADA compliant
• Optional perforated steel top and/or bottom diffuser
• Optional solid top to eliminate up light
• Dimmable to 10% standard
• Two lengths (18", 24") for scalable coverage
• Damp-location UL/CUL listing
• Proudly made in America; BABA-compliant options always available
• 5-year warranty on LED components, with optional 10-year warranty available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 1600
- 2420
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 12
- 18
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
