VTLVVTLV
24" - 96" Damp Listed Linear & Vanity Lighting
The VTLV-LED is a wall sconce built around a steel chassis and end caps with a white smooth acrylic diffuser that softly washes light up and down the wall, designed to mount to a standard J-box with slotted anchor holes in either vertical or horizontal orientation.
The fixture dims to 10% standard, with a configuration available that is both Energy Star qualified and Title 24/JA8 compliant. An independent nightlight circuit can be added for uplight-only operation after hours, and an optional concealed occupancy sensor and battery backup further extend the fixture's energy-saving and life-safety capabilities. Six lengths are offered to fit a wide range of wall spans.
The VTLV-LED is ADA compliant and damp-location UL/CUL listed, and is backed by Lightway's standard LED component warranty; consult the factory for line-voltage TRIAC/ELV dimming options.
Resources
Material: Steel chassis and end caps
Lens Material: White smooth acrylic; soft up/down wash distribution
Mounting: Mounts to a standard J-box with slotted anchor holes; vertical or horizontal orientation
ADA Compliant: Yes — 3" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: VTLV: 4¼" H x 3" D; available in 24", 36", 48", 60", 72", and 96" lengths
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Available in Energy Star-qualified configurations (F1Y)
Title 24 / JA8: Title 24/JA8 compliant (F1Y configuration only)
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The VTLV-LED's soft up/down wash profile brings ambient, ADA-compliant wall lighting to corridors and lobbies, with Energy Star and Title 24/JA8-compliant configurations available.
Ideally Suited For
• Hotel and multifamily corridors
• Lobby and reception accent walls
• California Title 24/JA8 energy-code projects
• Retrofit projects needing multiple length options
Key Features & Options
• ADA compliant
• Soft up/down wash light distribution
• Independent nightlight circuit (uplight-only)
• Dimmable to 10% standard
• Energy Star-qualified configuration available (F1Y)
• Title 24/JA8-compliant configuration available (F1Y)
• Optional concealed occupancy sensor
• Optional battery backup, 10W / 1170lm for 90 minutes
• Six lengths (24"–96") for scalable coverage
• Damp-location UL/CUL listing
• 5-year warranty on LED components, with optional 10-year warranty available
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 2000
- 3000
- 3235
- 4000
- 7260
- 9680
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 15
- 22
- 29
- 30
- 54
- 72
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Mounting
- Wall
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
- Photocell
