MRNW 16" – 26" Tall - Wet listed Wall Mount
The MRNW-LED is a distinctive outdoor LED wall sconce built on a steel chassis and cage, featuring a .10" extruded white acrylic diffuser encased in a series of horizontal ribbed rings that give the fixture a refined, layered architectural profile. Available in two heights — 16" and 26" — on a consistent 6" wide × 4" deep body, the MRNW is ADA compliant across all configurations. Top-and-bottom white acrylic lens caps are standard.
Standard 0–10V dimming to 10% is included. An optional photocell (adds 1½" depth) enables automated dusk-to-dawn control, and battery backup provides 90-minute emergency illumination. Optional 347V input accommodates Canadian projects, and a J-Box with all-side knockouts offers rough-in flexibility.
The MRNW-LED is ADA compliant, UL and CUL WET location listed, and Build America Buy America Act compliant, with a 5-year warranty on LED components.
Resources
Material: Steel chassis and cage; ribbed ring accent construction
Lens Material: .10" extruded white acrylic
Mounting: Integral mounting plate; keyhole slots
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: MRNW-616: H 16" × W 6" × D 4" | MC 8"
MRNW-626: H 26" × W 6" × D 4" | MC 13"
Lens Material: .10" extruded white acrylic
Mounting: Integral mounting plate; keyhole slots
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: MRNW-616: H 16" × W 6" × D 4" | MC 8"
MRNW-626: H 26" × W 6" × D 4" | MC 13"
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0-10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available.
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0-10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available.
The MRNW-LED's signature ribbed ring cage creates a unique horizontal texture that adds depth and character to any exterior wall, while its ADA compliance makes it a natural choice for accessible-route applications.
Ideally Suited For:
• ADA-accessible pathways and building entries
• Contemporary multifamily residential exteriors
• Boutique hotel and hospitality exterior lighting
• Mixed-use retail and lifestyle center entries
• Corporate campus and institutional building pathways
Key Features & Options:
• Distinctive ribbed horizontal ring cage design
• ADA compliant at 4" depth
• Two heights: 16" and 26"
• 0–10V dimming standard (to 10%)
• Optional battery backup — 90 min. emergency runtime
• Optional photocell (120V or 277V)
• Optional 347V input voltage
• J-Box with all-side knockouts option
• UL/CUL WET location listed
• BABA compliant — made in America
• 5-year LED component warranty
Ideally Suited For:
• ADA-accessible pathways and building entries
• Contemporary multifamily residential exteriors
• Boutique hotel and hospitality exterior lighting
• Mixed-use retail and lifestyle center entries
• Corporate campus and institutional building pathways
Key Features & Options:
• Distinctive ribbed horizontal ring cage design
• ADA compliant at 4" depth
• Two heights: 16" and 26"
• 0–10V dimming standard (to 10%)
• Optional battery backup — 90 min. emergency runtime
• Optional photocell (120V or 277V)
• Optional 347V input voltage
• J-Box with all-side knockouts option
• UL/CUL WET location listed
• BABA compliant — made in America
• 5-year LED component warranty
Ratings & Compliance
- ADA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- IP65
- Made in America
- Vandal Resistant
- Wet
Lumens
- 1210
- 2420
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
CRI
- 90
Shape
- Rectilinear
- Round
Lamp Source
- Integrated LED
Listings
- UL
Materials
- Acrylic
- Steel
Watts
- 9
- 18
Warranty
- 5 yr
- 10 yr
Static LED Color
- White
Voltage
- 120-277 V
- Multi Volt
- Multi-Volt
- UNV
Circuit
- Single
Color / Finish
- Anodized Silver
- Black
- Blue
- Brass Powder
- Bronze
- Cornflower Blue
- Custom
- Gloss White
- Parkers Blue
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Text Black
- Text Bronze
- Text White
- Textured Black
- Textured Bronze
- Textured White
- Tuscan Sun
- White
- Yolk White
Controls Options
- Infrared Sensor
- Integral Sensor
- Photocell
Dimensions
- L: 4 In. W: 6 In. H: 16 In.
- L: 4 In. W: 6 In. H: 26 In.
Lamp Base
- Integrated
