LTCWLTCW
12" Tall Damp lIsted Wall Lighting
The LTCW-LED wall sconce features a clean, contemporary silhouette defined by a curved white smooth acrylic lens with a separate top and bottom lens panel. The lens is deliberately offset ½" from the wall, creating a refined floating appearance that adds subtle depth to any surface. The steel chassis construction ensures commercial-grade durability while maintaining a slim ADA-compliant profile.
Three heights are offered — 12", 16", and 26" — all at a consistent 7.75" width and 4" depth, with the midpoint center (MC) ranging from 6" to 13" depending on size. Dimming is standard to 10%, with 0–10V and TRIAC/ELV options available across the configuration range. Optional integral battery backup (0–10V only) provides emergency egress capability for qualifying applications.
The LTCW-LED is ADA compliant, UL and CUL Listed for damp locations, Energy Star listed on select configurations, and Title 24/JA8 compliant on F1O and F1P configurations. Proudly made in America, backed by a 5-year LED component warranty.
Resources
Material: Steel chassis
Lens Material: White smooth acrylic with separate top and bottom lens; lens offset ½" from wall
Mounting: Wall mount — center lockup with hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: LTCW-12: 12" H × 7.75" W × 4" D (MC: 6")
Dimensions: LTCW-16: 16" H × 7.75" W × 4" D (MC: 8")
Dimensions: LTCW-26: 26" H × 7.75" W × 4" D (MC: 13")
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Yes — on select configurations
Title 24 / JA8: Yes — F1O & F1P configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The LTCW-LED is a refined, ADA-compliant wall sconce with a distinctive floating lens profile that elevates commercial corridors and public spaces. Its clean curved form and three available heights make it a versatile design element across a broad range of project types.
Ideally Suited For:
• Hotel guestroom corridors and elevator lobbies
• Healthcare facility hallways and patient room entries
• Office building common areas, lobbies, and restrooms
• Educational institutions requiring ADA-compliant wall lighting
• Restaurant and hospitality interiors seeking a modern, minimal wall sconce
Key Features & Options:
• ADA compliant — 4" projection from wall
• Three heights: 12", 16", 26" — all 7.75" wide
• Curved white smooth acrylic lens with ½" wall offset — floating appearance
• Separate top and bottom lens panels
• 0–10V dimming standard; TRIAC/ELV on qualifying configurations
• Optional integral battery backup (BB10 — 10 W, 90 minutes; 0–10V only)
• Energy Star listed — select configurations
• Title 24 / JA8 compliant — F1O & F1P configurations
• Made in America
• 5-year LED component warranty (optional 10-year available)
• UL and CUL Listed — DAMP location
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 2000
- 2420
- 2820
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Spherical
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 10
- 15
- 18
- 20
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
